Pvc Shrink Film Blowing Machine Fd-bm1600-pvc
Price:
Get Latest Price
In Stock
Product Specifications
| Film Width | 1200-1400 Mm |
| Film Thickness | 0.012-0.06 Mm |
| Screw Diameter | 100 Mm |
| Power | 160 Kw |
| Dimensions | 13500X5500X7200 Mm |
| Weight | 18000 Kg |
| Output | 90-120 Kg/H |
| Features | High Output, Uniformity, Easy Control, Durable, Efficient, Reliable, Precise, Cost-Effective |
Product Overview
Key Features
Following are the Main Features of PVC Shrink Film Blowing Machine FD-BM1600-PVC :-
Special screw designed mix extruder, cycle water cool for screw, It is melt sufficiently for PVC material in lower temperature.
Special die structure, it neither mandrill and distributary shuttle type. It more suitable PVC extrude,not dead angle,distribute uniformity.
The die is heated and refrigerate by the cycle oil.
Avoid the disadvantage of other heat type. It is easy to control the temperature.
Remote infrared heater, control by PVM, the temperature uniformity.
The second tow roller is silicon rubber,which can endure high temperature.
Rotate winder, the film roller can work for 30 days without tearing down the screw and die.
Technological parameter:
Film width1200-1400 mm
Film thickness0.012-0.06 mm
Screw diameter 100mm
L/D 25:1
Screw turn speed0~50rpm
Driver power55kw
Cylinder heater32kw
Output kg/h 90-120 kg/h
Die diameterI 200mm
Die heater10 kw
Width of Haul-off rollers1200/1600mm
Haul-off tow speed 0~60m/min
Film transverse shrinkage a Y45%
Film vertical shrinkage a 5%
Total powera 160kw
Out size13500A 5500A 7200
Weight18000kg
Special screw designed mix extruder, cycle water cool for screw, It is melt sufficiently for PVC material in lower temperature.
Special die structure, it neither mandrill and distributary shuttle type. It more suitable PVC extrude,not dead angle,distribute uniformity.
The die is heated and refrigerate by the cycle oil.
Avoid the disadvantage of other heat type. It is easy to control the temperature.
Remote infrared heater, control by PVM, the temperature uniformity.
The second tow roller is silicon rubber,which can endure high temperature.
Rotate winder, the film roller can work for 30 days without tearing down the screw and die.
Technological parameter:
Film width1200-1400 mm
Film thickness0.012-0.06 mm
Screw diameter 100mm
L/D 25:1
Screw turn speed0~50rpm
Driver power55kw
Cylinder heater32kw
Output kg/h 90-120 kg/h
Die diameterI 200mm
Die heater10 kw
Width of Haul-off rollers1200/1600mm
Haul-off tow speed 0~60m/min
Film transverse shrinkage a Y45%
Film vertical shrinkage a 5%
Total powera 160kw
Out size13500A 5500A 7200
Weight18000kg
