25 Sqmm X 2 Core Epr Round Cable - Copper Conductor, Epr Insulation, High Voltage Up To 6.6 Kv, Versatile Applications In Industry

Keeping in mind ever-evolving requirements of our respected clients, we are manufacturing and supplying a premium quality range of 25 SQMM X 2 Core EPR Round Cable in Delhi, Delhi, India.

CONSTRUCTION OF THE CABLE- Conductor of Annealed Tinned Cooper Conductor With Insulation of EPR ( Ethylene Proplene Rubber) ( IE-2 of IS:6380/84) with colour coding in accordance to the ISI standards of DIN VDE colour coding with sheathing of CSP ( Chloro Sulphonated Ethylene) or PCP ( Polychloroprene) in accordance to SE-3/ SE-4 of IS: 6380/84.

TYPES- FLAT CABLE
SIZE- 0.5 SQMM TO 630 SQMM ( SINGLE CORES & MULTICORES)
VOLTAGE GRADE- UPTO 6.6 KV GRADE ( 1.1 KV, 3.3 KV, 6.6 KV)

TEMP. CARRYING CAPACITY-CONTINUOUS OPERATING-TEMP. CARRYING CAPACITY

S.No. : TYPE : TEMP. OF THE CABLE : IN SHORT CKT. CONDITION
1. GENERAL SERVICE (VIR/TRS) : 70. DEG.C : 150 DEG. C
2. EPR/PCP : 110. DEG.C : 250 DEG.C
3. EPR/CSP : 120 DEG.C : 300 DEG.C

Special Cable Can Also Be Manufactured / Modified In Accordance To The Requirement For Special Application i.e. Nylon Braiding/ Reinforcement Can Be Given On The Inner Sheath ( For Reeling/Unreeling Applications), Braiding/Screening Of Copper On The Individual Cores Or Inner Sheath Of The Cables etc. & Also Cables Can Be Manufactured As per Customer Specifications.

APPLICATIONS-
EOT CRANES, BOILERS, WINDMILLS, MINES, SHIPPING, CONTROL PANELS, STACKER RECLAIMER, LIFT, ELEVATOR CABLES, FURNACE, TROLLEY CAR/TRIPPER TROLLEY etc.
