Industrial Battery Operated Motors - 60mm Diameter, 127.5mm Length, 12-24v Dc, 5000 Rpm | High Speed, High Accuracy, Replaceable Brushes, Easy Coupling, 5kgcm Torque

Expecting business momentum to pick up going forward, we are engaged as manufacturer, supplier and exporter of Industrial Battery Operated Motors in Pune, Maharashtra, India. This Permanent Magnet DC Motor is suitable for small and medium CNC machines and for replacement of stepper motors to DC servos which provides high speed and accuracy. This motor with drive can replace a stepper motor upto NEMA 34 size where high speeds are required. Motor runs on 12V to 24V DC and gives upto 5000 RPM on 24V. This motor may be directly coupled with ball screw linear system with a coupler. Reduction is possible with external timing belt and pulley system.
The Motor is a Industrial grade motor with replaceable carbon brushes,Keyway shaft and skewed armature for reduction of cogging effect.

Features:
5000RPM @ 24V DC
Keyway shaft 8 mm diameter, 20 mm length
Slot on shaft for easy coupling
Mounting PCD of 40mm x 4 holes.
Motor Diameter: 60 mm
Length: 127.5 mm without shaft
Weight: 1100gm with cables
5kgcm 2000 RPM
Replaceable Carbon Brushes
Can also be used as normal DC motor without encoder
No-load current = 600 mA
Stall current = up to 30A(Max)
