Spiral Plate Heat Exchanger Welding Robot

We are engaged in offering excellent quality Spiral Plate Heat Exchanger Welding Robot to our valuable clients.
Scope of application : This welding robot is mainly concentrating on the welding of spiral plate heat exchanger with diameter below 2500mm. It applies the advanced technology of vision tracking and three-axis linkage numerical control system with high precision to complete the stable tracking of the spiral platea s weld seam. It uses the CO2 shield semi auto welder to process the continuous welding with infinite rotary. It has the advantage of simple and convenient operation, high welding efficiency, high welding quality, high economic benefits and greatly reduces the labor intensity of workers and skill requirements.

Features:-
a c It applies the world's advanced technology of laser vision tracking to complete the stable and accurate tracking of the irregular weld seam.
a c It uses the three-axis linkage numerical control system with high precision to guarantee the stable equipment operation and welding quality.

Technology parameter:-
model number : SEWR-2500
Exchanger diameteri mmi : a I 2500
Welder control mode : Digital control for IGBT inverter
Exchanger heighti mmi : 500i 2000
Welding speedi mm/mini : 0i 1000
Handling frame lift strokei mmi : 1500
Welder rated output currenti Ai : 500
Welding torch lift strokei mmi : 0i 450
Welder rated load sustained ratei %i : 100
Welding and tracking mode : Vision tracking with unlimited rotary.
