Rotary Auxiliary Wiping Contact Switches

Being a customer centric organization, we are involved in manufacturing, exporting and supplying a supreme quality range of Rotary Auxiliary Wiping Contact Switches in Nashik, Maharashtra, India.

Rotary Auxiliary Wiping contact switches are modular in design and are very versatile for switching a.c. as well as d.c. resistive & inductive loads. They are used as auxiliary contacts in equipment such as HV - Gas Circuit Breakers and various equipment where in it is linked mechanically to the equipment and follows the position as per the linkage. In most cases a straight motion of main contacts is converted into rotational through links & levers.

Features

Wiping type of contacting making it suitable for switching d.c. loads.
Self cleaning of contacts is done during the operation.
Capable of carrying heavy currents.
Modular design to achieve any number of poles with minimum components.
Superior insulating material ensures electrical & mechanical stability.

Specifications:

Conventional free Air Thermal Current Rating (Ith): 20 Amp.
Operational Voltage: 264 volts d.c
Operational Current: 7.5 Amp.
Utilisation Category: DC13
Switching capability: Inductive loads with L/R ratio (time constant) of 20 m Sec
Dielectric Strength: 2.0 kv for 1 minute
Insulation Resistance: a Y500 Mohm
Mechanical Durability: a Y 1,00,000 operations
Electrical Durability: a Y 1,00,000 operations
