Rigid Box Grooving Machine - 2050x1320x1350mm, Grey And Blue | 40m/min Speed, 2kw Power, Precision Plc Control, Durable Wireless Belt

We are making, exporting and supplying Rigid Box Grooving Machine For Cardboard V Notching in Dongguan, Guangdong, China. LS-1200BRigid box grooving machine for cardboard V notching is newly invented based on the experience of older roller grooving machine. We apply the new technology which uses belts and roller together to convey the cardboard, this technology makes the grooving speed more faster. The product made by this machine is no rough edge,dustless, Noiseless, Smooth grooving. This machine equipped with special knife grinder, easy operating and seeting!

Specifications of Rigid box grooving machine for cardboard V notching
Model No
LS-1200B
Quantity of grooved at a time
8 slots
Working speed
40m/min
Motor power
2Kw
Voltage
380V
Cardboard size
140*120-800*600mm
Cardboard thickness
1-4mm
Machine dimension
2050*1320*1350mm
Machine weight
1250kg

Machine Parts
Name: Wireless belt
Original: Italy
The automatic feeding part has applied the wireless belt which is imported from Italy. It has higher friction force and durable. It doesn't need to adjust the pressure of each belt. so that will save the time to adjust machine.
Main Features
Name: Feeding area
Original: China
It need manual to feeding the cardboard one by one.

Machine Parts
Name: Big roller
Original: China
The diameter of this roller is 60cm. It can groove the cardboard size at 140*120mm to 800*600mm. After applying the roller and belt to convey the cardboard, the grooving speed become faster.
Main Features
Name: Blade holder
Original: China
It is using for hold the blade. The distance between blade and roller is adjustable.
We have built good and long-term cooperation with several world-famous companies. Our market has been expanded to all over the world.

We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.
