Hitec Hs-485hb Deluxe Hd Ball Bearing Servo

With its top ball bearing, heavy-duty, high impact Karbonitea c gears and high performance circuitry, the Hitec HS485HB offers lots of torque and features excellent centering and resolution.
Applications: Heli's and Aircraft up to 72a or up to 12lbs when using just one servo per control surface.

Features
Top Selling Heavy Duty Standard Servo
High Impact Karbonite Gears
Top Ball Bearings
Excellent Centering and Resolution

HS-485HB Servo Specifications
Performance Specifications
Operating Voltage Range (Volts DC)4.8V ~ 6.0V
Speed (Second @ 60A )0.22 ~ 0.18
Maximum Torque Range kg. / cm.4.8 ~ 6.0
Current Draw at Idle10 mA
No Load Operating Current Draw200 mA
Stall Current Draw1,200 mA
Dead Band Width3 Aus

Physical Specifications
Dimensions (mm)39.8 x 19.8 x 38.0
Weight (Gram)45.0
Circuit TypeHT7003 Analog SMT
Motor Type3 Pole Metal Brush Ferrite
Gear MaterialKarbonite
Bearing TypeTop Ball Bearing
Output Shaft (type / A mm)Standard 24
Case MaterialPlastic
Connector Gauge (AWG) / Strand Count25 / 40


Radio Control Applications
Sport Plane50 - 64 oz.
Sailplane2 meters and up
Scale50 - 64 oz.
Sail Boat< 1 meter
Power Boat1/10th
