Hd-604b-s Computer Servo Control Double-column Tensile Testing Machine

Our range of HD-604B-S Computer Servo Control Double-Column Tensile Testing Machine is available with following specifications:-
1.Computer servo control large deformation jig
2.Apply to hardware metal rubber leather wire fabric
Tensile Testing machine
These series of tensile strength tester are used to test tension compression shearing force adhesion peeling force tear strength ...etc. of specimen semi-product and finished product in the field of rubber plastic metal nylon fabric paper aviation packing architecture petrochemistry electric appliance automobile ...etc. which are the basic facilities for input quality contorl (I.Q.C) Quality Control (Q.C.) Physical Inspection Mechanics Research and Material Development.

Tensile Testing machine
Model HD-604B
Capacity (optional) 50kg 100kg 200kg 500kg 1T 2T
Unit (Switchable) G KG N LB
Load Resolution 1/100000
Load Accuracy a 0.5%
Stroke (include the grips) 1000 mm
Test Speed 20~300 mm/min selectable
Effective Width 400 mm
Operation Mode PC
Weight Approx. 150Kg
Display PC
Motor AC motor with variable freq. drive
Dimension(LA WA H)-Main Unit 985A 510A 1600cm
Power 1? 220V/49Hz
Rotation method high-precise ball screw rod
Accessories Tensile grips 1 set
Design criteria GB/T16491 GB/T1040 GB/T8804.1-2 GB/T8808 GB13022
