White Fh 9 Brinell Hardness Testers

Under the assistance of our professionals we are engaged in manufacturing exporting and supplying a wide spread of FH 9 Brinell Hardness Testers in Noida Uttar Pradesh India. Customers can avail this product from us at market leading rates.

Product Details:-
Data OutputRS-232 Bi-Directional USB WLAN LAN RJ45
Power Consumption390W
Power Supply100V AC to 240V AC 50Hz/60Hz single phase
Weight130 kg (286.6 lb) / 160 kg (352 lb) XL model
Operating Humidity Range10% to 90% non-condensing
Operating Temperature Range10 to 35 Degree C
Dwell Time SettingDefault 10 seconds user defined 1 to 99 seconds

The FH-9 is a quality Brinell testing system in a robust rigid frame. It integrates a precision optical system with high-quality objectives and a digital display and offers conversion to other hardness scales and online statistics as well as an RS-232 data output.

Features and Benefits:-
Load cell closed-loop system
Test loads 62.5 kgf/612 N - 3000 kgf/29 kN (137.8 lbf - 6614 lbf)
LCD display showing Brinell value statistics and tester settings or 7.5"full-colour touchscreen on selected models.
Simultaneous conversion to Rockwell Vickers and Leeb rebound testing
Microscope with 20x magnification and analog scale for indentation measurement (analog models FH-9-0 FH-9-1 and FH-9-17)
Standard Brinell digital scanner (CCD camera) for automatic indentation measurement (on selected models)
Extended frame (XL) versions available with 390 mm (15.35") workpiece height and 220 mm (8.66") throat depth
Horizon High-performance PC- based camera indent measuring system. Automatic measurement of the indent on the LCD screen. Store file handle images and data on the hard disk.(selected models)
