Electric Stacker He1200/3 Lifting Height 3000mm 1200kg Solid Hub - Attributes: Easy To Operate

The SolidHub HE1200/3 is a cost-effective alternative to purchasing a forklift. Small businesses, in particular, may lack the space, or trained personnel to purchase a powerful forklift. Thanks to its waterproof control unit, this high-quality high-lift truck is perfectly suited for tough working conditions such as cold, damp, and dust, and is ideal fortemporaryuse in cold stores and production halls, for example. The HE1200/3 is not designed for permanent use in cold stores or freezers, or in rainy or damp conditions.

The HE1200/3 facilitates the handling of loads up to 1,200 kg and a lifting height of 863,000 mm. The low noise level of 69 dB allows for comfortable working over long periods. The dimensions of the maneuverable, fully electric high-lift truck are perfect for use in confined storage and production spaces. However, the mast height (2,0003,424 mm) must be taken into account, depending on the extension status. The ergonomically designed tiller allows user-friendly control of all lifting and lowering functions via the multifunction tiller knob. All important operating instruments, such as the battery charge indicator, hour meter, emergency stop switch, and key, are centrally located and in the driver's direct field of vision. Additional protection is provided by the full bodywork and the low ground clearance, which reduces injuries to the foot area. Due to the low ground clearance, it is important that the HE1200/3 is only used on smooth, level surfaces and on ramps. The low height of the housing and the truss design of the mast ensure excellent visibility through the telescopic mast people and goods are always in view. The 0.75 kW motor power perfectly supports you in transporting Euro pallets and mesh boxes up to 1,200 kg. The 100 Ah battery capacity guarantees a total operating time of 4 hours at full capacity. The two built-in lead-gel batteries are maintenance-free and have a combined voltage of . They can be easily charged via any standard 230 V socket, and charging takes approximately 7 hours from a fully depleted battery.

Lifting speed:

- loaded 92 mm/s
- unloaded 136 mm/s

Descent rate:

- loaded 112 mm/s
- unloaded 98 mm/s

The transport speed of 4.2 km/h is approximately the speed of a pedestrian. An electromechanical brake ensures safe transport of goods. Depending on the load, the electric pallet truck can be used on inclines of up to 6-8%. These specifications apply only to smooth industrial floors. The smooth-running, easily maneuverable PU wheels and high-quality ball bearings are standard equipment on the SolidHub HE1200/3. Please consider your floor load before using the HE1200/3. Spare parts can be supplied at any time within 48 hours through our spare parts service. Check the compatibility of your pallets with the HE1200/3 using our technical data sheet.

Good to know for use in Germany:Warehouse employees do not require special training or a forklift license. However, they must be at least 18 years old. An introduction to using the lifting equipment is sufficient. When working with the SolidHub Electric Pallet Truck HE1200/3, all legal regulations must be observed and adhered to.

Before use, check the applicable national regulations in the country of use. The commissioning engineer is responsible for commissioning the device and selecting suitable personnel for its operation.

IMPORTANT - Handling the battery:
Follow the instructions for using the battery in the user manual. It is important that the battery never be allowed to fully discharge. Therefore, it is recommended to charge the battery regularly, even when the device is not in use.
