Black Nylon 500v Ac Worm Drive Limit Switch

Application: The new range of limit switches has been designed and manufactured according to safety standard are suitable for use on reversing drives such as hoists, cranes, winches and rolling mills. Design: The driving motion is transmitted by worm gear. All gears and hubs are made of low wear thermoplastic. The rotational movements are transmitted to switches by adjustable cams. Driving cams: Each lever has a single micro metric resister screw. This screw exclusively works on its own combined lever, excluding any mechanical contact with any other next to it. The regulation is easily made by use of screwdriver on a register screw. The special friction system assures a rapid and precise adjustment. Technical Data: Body Material : Black Nylon Cover Material Yellow : Impact proof thermoplastic Protection Degree : IP-55 Mounting Position : Any Gear Ratios : 1:12.5, 1:25, 1:50, 1:100, 1:200 & 1:400 Drive : Worm Drive Cable Entries : 2, 3/4" Conduit Maximum Rotation Speed : 1200 rpm Contact Material : Double break silver cadmium Wire Connection : Screw terminal Rated Voltage Insulation : 500 V.A.C Thermal Test Current : 10 Amps
