Automobile Vehicle Wash Effluent Treatment Plants (Etps) - Lifting Capacity: 500 Kg 5000 Kg (Standard: 1 Ton / 2 Ton / 3 Ton) Kilograms (Kg)

Automobile Vehicle Wash Effluent Treatment Plants (ETPs) are designed to treat wastewater generated from vehicle washing activities at car wash centers, bike wash stations, and automobile service workshops. These treatment systems efficiently remove oil, grease, suspended solids, and detergents, enabling water reuse and compliance with pollution control regulations.

*Capacity :Customizable, commonly available from 1 KLD up to 20 KLD or higher depending on volume of wash water.

* Technology :Physico-chemical treatment combined with biological processes and advanced filtration.

Treatment Steps:

* Oil and Grease Separation :Efficient oil skimmers remove floating oils and grease.

* Coagulation and Flocculation :Chemical dosing to aggregate suspended solids and emulsified oils.

* Dissolved Air Flotation (DAF) :Removes flocculated matter and fine solids.

* Biological Treatment :Aeration tank with microbial degradation of organic load.

* Sedimentation :Clarifies treated water by settling sludge.

* Tertiary Filtration :Pressure sand filter (PSF), activated carbon filter (ACF), and bag filters for final polishing.

* Ultrafiltration (UF) Membrane :Optional for removing colloids, bacteria, and fine suspended solids.

* Disinfection :Chlorination or UV treatment.

* Water Saving :Recovers and recycles up to 80-90% of used water, significantly reducing fresh water consumption.

* Automation :Ranges from semi-automatic to fully automatic systems often equipped with IoT-based control and monitoring.

* Compact Design :Skid-mounted or containerized units for easy installation in limited spaces.

* Sludge Management :Sludge dewatering units reduce sludge volume by 80-85%, producing dry sludge cakes for safe disposal or reuse.

* Applications :Commercial car and bike wash stations, fleet washing facilities, malls, hotels, and automobile workshops.

* Compliance :Designed to meet PCB discharge norms for treated effluent quality.

* Operational Benefits :Low operational costs, easy maintenance, and reduced environmental impact.

Car Wash ETPs integrate advanced physico-chemical and biological treatment technologies, maximizing water recovery and pollutant removal for vehicle washing applications. These systems support sustainable water management in the automobile industry while ensuring regulatory compliance, operational efficiency, and cost savings.
