Alcohol Breath Analyser - E100 Electrochemical Measuring Cell, Active And Passive Measuring Modes, Measuring Range 0 To 5.5ⰠBac, High Accuracy ± 0.05ⰠAbsolute, Stores 9999 Measured Values With Date And Time

Advanced new Technology for Reliable Technical data Device Measuring modes: Active and passive Measuring range 0 to 5.5 BAC Accuracy Max. Measuring error, in relation to the ethanol standard: Range 0 to 1 0.05 absolute Range 1 to 2 5 % of measured value Range > 2 10 % of measured value Standard Deviation 0.008 Ambient conditions Temperature range -5C to +50C / +23F to +122F Temperature range storage -20C to +60C / -4F to +140F Optimum storage temperature 0C to +25C / +32F to +77F Ambient pressure 600 to 1400 hPa Ambient humidity 20 to 98 % r.h. Minimum expiration volume 1.2 liters or depending on requirement Batteries 4 x LR6 (AA) Mignon cells Number of measurements more than 1600 tests, Per battery pack depending on the batteries and the ambient conditions Device interface RS-232 (serial interface). Data can be transferred to a PC or printer. Dimensions (L x W x H) 190 mm x 61 mm x 51 mm Weight 275 g incl. Batteries Miscellaneous Ready to measure after switching on: approx. 6 sec. Ready to measure after 0 measurement approx. 2 sec. Ready to measure after 1 measurement approx. 5 sec. Sensor type E100 electrochemical measuring cell Cross sensitivities negligible for other substances, e.g. acetone, CO etc. Measurement units all units used worldwide configurable Operation Menu-driven with clear text information Input Three-key operation Power-saving mode Device switches off automatically after 2.5 minutes of non-operation; the background lighting switches off after 15 seconds Display Background illuminated, fully graphic Data memory Stores 9999 measured values with date and time Software PC software for statistical analysis, data transfer and logging Calibration Every 6 months
