Air Core Smoothing Reactor For Metallurgical Rectifier Feed System

We are involved in manufacturing, exporting and supplying Air Core Smoothing Reactor For Metallurgical Rectifier Feed System.

1. Air Core Smoothing Reactor for Metallurgical rectifier feed system is normally used for reducing the harmonic component of voltage and current in the DC system

2.liming the rapid rise speed of fault current under the fault condition, and limited the current value of short-circuit.

3.It is usually used for the high voltage DC system and large rectifying and feeder system of steel and iron nonferrous metallurgy industry.


Basic Ordering Data:
Rated Current: 30~6000a
System Voltage: 1.2 Kv
Weight: 10~2330kg
Rated Inductance And Its Margin: 0.1~5.5mh
Cooling Method(An Or Af)
Product Executive Standard: Jb5346 Gb10229 Iec289

Customer benefits:

1.High harmonic stress resistance
2.Very low losses
3.Low noise
4.Long operating life expectancy

Service conditions:
1. Service site: indoor or outdoor
2. Ambient temp.:-40~40 degree( or according to customer's requirement)
3. Altitude: <=10000m( if it exceeding to 1000m, please declare in order).
4. Max. Wind speed: 35m/s
5. Relative humidity: <=90%
6. Earthquake resistant capability: horizontal direction 0.3g vertical direction 0.15g (or by customer's requirements)

The Basic Program Of Testing Includes
Some Or All Of The Following Tests:
Routine Tests
Impulse Tests
Thermal Current Calculation
Mechanical Strength Test
Impedance And Loss Test
Temperature Rise Test
Sound Level Test
Seismic Analysi
