4 Wheel Roller Conveyor Type Shot Blasting Machine

We manufacture, export, distribute and supply of 4-Wheel Roller Conveyor Type Shot Blasting Machines in Jodhpur, Rajasthan, India. The Tunnel type/ roller conveyor shot blasting machine is best suitable for the shot blasting of Round/Hex/Square Rods/bars/Pipes etc. It consists of inlet and outlet side Roller conveyors as material handling systems. The components to be blasted are placed on inlet side of the roller conveyor, from where it travels forward and enters into the inlet tunnel. After passing through the inlet tunnel components enters into the blast zone which consists of 4 nos of Blast Wheels. All these Blast wheel units are strategically placed around the Blast cabinet. The arrangement of the blast wheel ensures optimum blast cleaning and maximum utilization of the abrasive energy. Blast wheels fires the abrasive at high velocity on the forward moving components & blast cleans them thoroughly. Blasted material moves forward and enters into the outlet tunnel. The spent abrasive from blasting operation after passing through the perforated floor plates will get collected into the cabinets bottom storage hopper. From where it is transferred to the bucket elevator, which elevate the abrasive vertically and discharges the same into a media separation unit where dust and fine abrasives are cleaned ensuring that only clean abrasive will re-circulate to the blast wheel units for effective and better cleaning.
