Zrj-300l Vacuum Emulsification Mixer

We are instrumental in providing to our valuable customers excellent quality ZRJ-300L Vacuum Emulsification Mixer which is available with following specification:-
1. Outer dimension: main machine: 3200A 2500A 2250 MM; The maximum lifting height: 3200.
2. Emulsification Tank: working volume: 300L; material: SUS316L; electricity heating and steam heating, water cooling
3. Structure: three layer, top and bottom sealing heads, top sealing head connecting with the tank by the flange, bottom sealing head connecting with the tank directly, the material for inner side of the tank is 316L, thickness: 6mm, inner polish: 300MESH(hygiene grade), jacket material: SUS304, thickness: 4mm, working pressure: 0.3Mpa, heat preservation coat: 304, thickness: 2mm, outer polish: 300MESH(hygiene grade), weld crack polish, heat preservation material, adopting on PU bubble liquid working art.
4. There are three sets of mixing system in the tank:
1. High speed scissors: power: 5kw; turn speed: 0-3200r/min
2. Overflow frame-shape mixer: power: 2.2kw; turn speed: 70r/min
3. Backwards mixer: 2.2kw; turn speed: 0-70r/min
5. Main parts from the tank: product inlet filter; product fitting inlet; vacuum sucking outlet; germless breath mouth; mirror with light and brush; temperature sensor; CIP cleaner; product outlet; safety valve; pressure meter; negative pressure sensor, etc.
6. Hydraulic pressure system:
Oil box, oil cylinder, electromagnetic valve, overflow control valve.
