Wired Pir Motion Sensor

Get Latest Price

In Stock

Product Specifications

FOB Port	Shenzhen
Payment Terms	Paypal, Cash in Advance (CID), Telegraphic Transfer (T/T), Western Union
Supply Ability	50000 Per Month
Delivery Time	15 Days
Sample Available	Yes
Sample Policy	Sample costs shipping and taxes has to be paid by the buyer
Main Export Market(s)	Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market	All India

Product Overview

Key Features

The Athenalarm AT-805 is a wired indoor PIR (Passive Infrared) motion sensor for conventional intrusion alarm systems. It uses a dual-element pyroelectric infrared sensor with Fresnel lens optics, true temperature compensation, 3-level adjustable pulse counting, and anti-RF interference protection (20V/m, 10MHzAcA A 1GHz). It delivers a 12m detection range, 110A A detection angle, selectable NO/NC alarm output, and a dedicated NC tamper output.

Suitable for residential, office, retail, warehouse and factory security. Available for wholesale, bulk order, and OEM/private label (MOQ 100pcs, 5-day lead time, 1-year warranty).

Key Specifications
ParameterSpecification
ModelAT-805
TypeWired indoor PIR motion sensor
SensorDual-element pyroelectric infrared
OpticsFresnel lens
Detection Range12 m
Detection Angle110A A
Operating VoltageDC 9AcA A 16 V
Quiescent CurrentAcA A 18 mA @ DC 12V
Alarm OutputNO/NC selectable, DC28V/100mA
Tamper OutputNC, DC28V/100mA
Temperature CompensationTrue temperature compensation
Pulse Counting3 selectable levels
RF Interference Immunity20 V/m, 10MHzAcA A 1GHz
Operating Temperature-10A A C to +50A A C
HumidityAcA A 95% RH, non-condensing
InstallationWall/corner, height 1.7AcA A 2.5m
Self-Test Time~60 seconds
Dimensions83 A A 90 A A 110 mm
ManufacturingSMT
Warranty1 year
Key Features
12m/110A A dual-element PIR coverage with Fresnel optics for reliable indoor detection
True temperature compensation AcA A stable performance under changing ambient temperature
3-level adjustable pulse counting AcA A balance sensitivity vs. RF-interference resistance per site
Anti-RF & anti-white-light interference, tested to 20V/m (10MHzAcA A 1GHz)
Selectable NO/NC alarm output AcA A compatible with most conventional alarm panels
Independent NC tamper output for enclosure protection
Wall or corner mount, SMT-manufactured for consistent quality control
Low MOQ (100pcs), 5-day lead time, OEM/private label available
Jumper Configuration
JumperSettingFunction
PULSE1&2Class 1 AcA A high sensitivity, standard RF resistance
PULSE2&3Class 2 AcA A high sensitivity, stronger RF resistance
PULSEDisconnectedClass 3 AcA A lower sensitivity, highest RF resistance
RELAY1&2NO
RELAY2&3NC (factory default)
LED1&2LED ON
LED2&3LED OFF (no effect on detection)
Terminal Connections

+12V / GND: Power input (DC 9AcA A 16V)
ALARM: Configurable NO/NC relay output (DC 28V, 100mA)
TAMPER: Dedicated NC tamper output (DC 28V, 100mA)
Before deployment, confirm alarm panel compatibility: supply voltage (DC9AcA A 16V), current budget (AcA A 18mA), NO/NC input type, and tamper input.

Installation Guidelines
Mount on wall (height 1.7AcA A 2.5m) or corner; surface must be solid and vibration-free
Position so intruders cross the detection field rather than walk directly toward the sensor
Avoid: outdoor use, direct sunlight, HVAC vents, heat sources, rotating fans, unstable surfaces, or areas with pets
After power-up, allow ~60s self-test, then perform a walking test to confirm alarm response before commissioning
Recommended: weekly walking test for ongoing system verification
Applications
Residential (homes, villas) A A. Commercial (offices, retail, malls) A A. Industrial (factories, warehouses, storage) A A. Conventional wired alarm system integration projects

B2B / OEM / Wholesale Information
ItemStatus
Sample AvailabilityYes
MOQ100 pcs
Lead Time5 days
OEM / Private LabelYes (logo, packaging, manual customization)
Warranty1 year
For a fast quotation, please provide: quantity, destination country, sample requirement, OEM/private-label needs, packaging requirement, and target alarm panel/system (if applicable).

FAQ
Q1. What is the AT-805?
A wired indoor PIR motion sensor with a dual-element pyroelectric infrared sensor, for use with conventional intrusion alarm control panels.

Q2. What is the detection range and angle?
12 meters detection distance, 110A A detection angle.

Q3. What power supply does it need?
DC 9AcA A 16V, quiescent current AcA A 18mA at DC12V.
