Utm Controller By N.r. Enterprises

The L2 Indicator is a high performance and rugged instrument designed for any type of Load Testing Machine application, to operate under any type of conditions. It is specifically designed for motorized machines.

It measures the Force in compression (positive values) as well as tension (negative values). Similarly, the Position display is of incremental type, so that the reference zero position is of floating type, and any value relative to that position is displayed (positive in one direction and negative in opposite direction).

Apart from showing direct Force and Position values on its dual displays,

it has got many other features such as

GENERAL TECHNICAL SPECIFICATIONS:

Load cell excitation - ± 5V DC

Input signal range - 0 to 20 mV

Internal resolution - 20,000 counts or 40,000 counts

Non- linearity - +0.05 % of F.S.

Operating temperature range - 0 °C to +50 °C

Storage temperature range - 10 °C to +70 ° C

Operating voltage - 230 VAC ±10% 50 Hz

Calibration Full digital software calibration through keyboard

Settings Set Points, Digital Filter, Baud Rate and Data Collection Settings by software

through keyboard

Displays 5 digit 7 segment LED 12.7mm with negative sign, 1 each for Force and Position Visual Indications (with LEDs) Overload Alarm, Peak Force, Set Points, Data Collection in progress, Data Collection Over Audio Indication (with buzzer) Force Overload

Housing type and size Table Top Mounting with Tilt Stand, 144 mm x 144 mm x 250 mm
