Top Rated Digital Transmitter

With the help of skilled professionals and good knowledgeable experience, we are involved in supplying, exporting and manufacturing quality-assured spectrum of top rated Digital Transmitter in Pune, Maharashtra, India.

Product Details:
Minimum Order Quantity10 Unit
Power0-10 v DC
ApplicationTransmitting device

Salient Features:
Full Software Calibration
Available in various types of housings
Various input options such as mV, mA, DC Voltage, ohms, TTL pulses, etc.
Various output options such as RS232, RS485 (MODbus), 4-20 mA, 0-5/10 VDC, Set Points with relay contacts, etc

Applications:
Building energy management systems
Commercial & residential sectors
Clean rooms
Museums
Climate chambers

Technical Specifications:
Sensor excitation5V DC
Sensor drive capacity2 nos. 350 sensors (Optional up to 8 nos.)
Sensor connection4 wire or 6 wire
Input signal range0 to 30 mV (other input options on request, such as 0-100 mV 0/4-20 mA, 0-5 VDC or 0-500 )
Internal resolution20,000 or 40,000 counts (selectable)
Display resolution1,000 to 15,000 counts (as per application)
Display full scale65,535 counts
Non- linearity0.05 % of F.S.
Zero temperature co-efficient0.01% RO/C/h
Span temperature co-efficient0.01% RO/C/h
Drift of no-load output with temperature0.05 % of F.S.
Drift of no-load output after 1 hour0.05 % of F.S.
Drift of full scale output after 1 hour0.01 % of F.S.
CalibrationFull digital software calibration (through separate display module
SettingsSet Points, Digital Filter, Baud Rate and Analog Output Settings
Re-transmission outputsRS232C, RS485 (MODbus protocol), 0/4-20 mA, 0-5/10 VDC
