Swing Type Check Valve

Swing Check Valve

The Non-return valve or the Check valve is one of our most
commonly used products in various industries. Being in this industry for
several years, we have established ourselves as a trusted Non-Return Valve
Manufacturer known for quality and performance. This unidirectional valve has a
simple yet efficient design to regular water and other fluids in an industrial
setup.

Our team of engineers study applications and functionalities of
industrial valves and design highly task oriented products. The Check valve is
an automatic design that opens with forward flow and seals with reverse flow,
thus preventing backflow. Even under high pressure and varied temperature, the
Non-return valve exhibits minimum turbulence. As the top Industrial Valves
Manufacturers in India we source our raw materials and components from trusted
vendors. Subjecting each valve to a wide array of tests, we ensure their safety
and superior sealing.

It is our determination and thirst for
excellence that has made us one of the best Industrial Valves Manufacturers in
India. Along with customisation options and durable products, we offer our
clients the best in the business customer support as well.






Material


Size Range


Construction


ANSI Class


Mfg Standard




Cast Carbon Steel/
Cast Alloy Steel


2 To 24


Bolted or Pressure Sealed


150 # -2500 #


BS 1868 API 6D




Cast Stainless Steel


2 To 24


Bolted or Pressure Sealed


150 # -2500 #


BS 1868 API 6D




Bronze


2 To 8


Bolted Bonnet


150 # -600 #


BS 1868 API 6D









Temperature Range


100 C to 600 C




Pressure Rating: Vacuum


Up to 621 Bar kg/cm2




Mfg. Standard


BS 1868




Ends to Ends Dimension


ANSI B 16.10




Inspection Standard


API 598 / BS 6755




Ends


Flanged/ Buttweld




Applications
:Chemicals,
Fertilizers, Feed Water, Petroleum, Power Generation, Steel Industries and
Effluent Treatment Plants.

Operators :Automatic/ Hydraulic Damper/
Counter Weights.
