Stability Chamber - Stainless Steel Inner Chamber, 171l To 336l Capacity | Dual Pid Control, High-grade Puf Insulation, Transparent Door, Adjustable Humidity Up To 95% Rh

We are highly dexterous company engaged manufacturer and supplier of Stability Chamber in Delhi, Delhi, India. RESONANCE AUTOMATION AND MACHINES Suitable for carrying out different quality control tests under controlled conditions of temperature and humidity. Inner chamber and trays made of SS sheet and outer body of MS sheet duly epoxy powder coated. The gap between the outer and inner wall is filled with high grade PUF insulation to prevent thermal losses. Double walled door is provided with a transparent see through window, magnetic synthetic rubber gasket and lock key arrangement. A air circulation fan is fitted to maintain uniform temperature and humidity conditions throughout the chamber. Temperature range from 5A C to 60A C is controlled by Microprocessor based PID Digital Temperature Indicator cum Controller with an accuracy of A 1A C. Humidity is created through steam injection arrangement and is controlled through an Digital Humidity Controller, thus controlling the desired set humidity range from atmospheric humidity to 95% A 3% RH.

MODELS
INNER DIMENSIONS (WxDxH)
CAPACITY
NO. OF SHELVES
EC-06
505 x 415 x 830 mm
171 ltrs. (6.1 cuft.)
2
EC-10
570 x 555 x 875 mm
276 ltrs. (10 cuft.)
3
EC-12
650 x 580 x 900 mm
336 ltrs. (12 cuft.)
3
Optional : Automatic Voltage Stabilizer (Highly Recommended
