High Tensile Steel Solar Energy Alarm Device 10.5m Overlong Boom 3 Tons Stiff Boomed Loader Crane

Solar Energy alarm device 10.5m overlong boom 3 tons stiff boomed loader crane
A truck-mounted crane has two parts: the carrier, often referred to as the lower, and the lifting component which includes the boom, referred to as the upper.
We prodcue the stiff booed and knuckle boomed cranes which is mounted on the different truck chassis from different manufacturer. The truck can still be used to transport the materials instead of only a carrier of the crane.
The crane can be noted as truck-mounted crane, loader crane, lorry crane.
Besides lifting and lowering materials, the crane can have some very different functions by equipped some accessories, such as a petal grasper, or a rotary head to use as a drilling machine, shown as the following pictures.

The newly developped crane is with some safety device, such as the light for night work, solar engery driven alarm device. and also can have a moment limiter to protect the crane as well as the operator.

We produce a lineup of the cranes, telescopic boomed and knuckle boomed, the lifting capacity is from 1 ton to 20 tons.

Besides mounted on the truck-chassis, the crane can be also mounted on the boat, in the workshop, the top of the tower. we have this experience to make a special design for the clients of India.

Modle: QYS-3.2III
Max. working radius: 10.5m
Max. lifting height: 11.2m (from the mounting surface)
Max. lifting capacity: 3.2 tons

Features:
1. Overlong boom, the max. working radius can reach 10.5m, the lifting capacity is 400kgs at 10.5m
2. big outigger span to make a good steability and safety factors.
3. integrate swivel, more soomth and low fault rate.
4. good quality valve lock.
5. solar energy alarn devuce to gurantee the safety.
6. equipped with working light for the working at night.
7. optional rear outigger.

Modeli QYS-3.2III
Max. lifting momentkN64
Max. lifting weight kg3200
Max. lifting height m11.2 (from mounting surface)
Max. working radiusm10.5
Luffing angle A 0-75
Swivel angle A clockwise and anti-clockwise 360
Rated working pressureMpa17
Max. lifting height m20
Rated flow rate of hydraulic systemL/min30
Sections of boom 5
weight kg1300
Sections of boom 4
Outrigger span mm2080-4300
Optional rear outrigger
fixed, vertical telescopic, horizontal fixed
Lifting capacity 3.2ton at 2m
