Rotary Vacuum Evaporator

ROTARY VACUUM EVAPORATOR

Consist Of An Evaporating Flask Rotated By A Non-Sparking Induction Motor In A Heating Water Bath. Vacuum Distillation Of Solvent At High And Low Temperature Is Achieved Quickly And Efficiently By Use Of Speed Controller. It Prevents Foaming An Vacuum And Bumping Of The Liquid. Other Application Include Vacuum Drying Of Powders And Slides. Low Temperature Vacuum Distillation Of Heat Sensitive Compounds. The Introduction Tube Permits Continuous Feed Of The Liquids Into Evaporating Flask And Also Distillation Under Controlled Atmosphere. The Evaporating Flask, Pear Shaped To Give A Larger Surface Area For Evaporation, Is Clamped To A Glass Duct Which Goes Through The Drive Unit And Protrudes 120 Mm. Into The Condenser. The Condenser Is Screwed Into The Drive Unit And Contains A Ptfe Inlet Feed Tube At Its Upper End. Condenser Is Fitted With Standard B-19 Joint At Top And Spherical Joint S-35 At The Bottom For Receiver Flasks. Drive Unit With F. H. P. Motor, Speed Regulator, Heavy Cast Iron Stand With Steel Rod. Evaporating Flask 1 Liter (Approx.) With Standard B-29 Joint. Glass Duct All Glass Connector Cone With B-29, Connected Evaporating Flask And Protrudes In The Condenser. With Clip To Hold The Evaporating Flask With Glass Duct. Condenser Double Coil Condenser For Water Circulation, Fitted With Vacuum Connection And Standard S-35, Ball Joint For Receiving Flask With Condenser. Receiving Flask 1 Liter Capacity With Standard S 35 Ball Joint. Ball Joint Clamp To Hold The Receiving Flask With Condenser.
