Rotary Airlock Valve By Fourteckh Enviro
Price: 145000 INR / Unit
Get Latest Price
Minimum Order Quantity :
1 Unit
In Stock
Product Specifications
| Sealing | Gland type with PTFE packing or general sealed/dust-tight construction to prevent air leakage |
| Size | 200x200 mm |
| Connection | Flange Type |
| Finish | Other |
| Voltage | 220V, 240V, or 380V-440V (3-phase) Volt (v) |
| Usage | Regulating flow and maintaining airlock conditions in pneumatic conveying/dust collection systems |
| Material | Cast Iron |
| Media | Other |
| Height | Varies by manufacturer/model Millimeter (mm) |
| Temperature of Media | Standard range up to ~250 C (specials up to 1200 C) Celsius (oC) |
| Product Type | Rotary airlock valve, rotary feeder, or square rotary valve |
| Port Size | 200x200 mm inlet/outlet size |
| Weight | 75 kg to 120 kg Kilograms (kg) |
| Flange | Square flange (200x200 mm ID); specific PCD and hole dimensions apply (e.g., 298 mm PCD, 8 holes) |
| Color | Silver, blue, off-white, or various painted/powder-coated finishes |
| Width | 200x200 Millimeter (mm) |
| Length | 200 Millimeter (mm) |
| Application | Industrial applications, pneumatic conveying systems, dust collection, pharmaceutical production |
| Payment Terms | Cheque, Cash Advance (CA), Cash in Advance (CID) |
| Supply Ability | 100 Per Month |
| Delivery Time | 1 Week |
| Sample Policy | Contact us for information regarding our sample policy |
| Packaging Details | Industrial Standard |
| Main Domestic Market | All India |
Product Overview
Key Features
Rotary Airlock Valve (RAV) is the equipment which is fitted below the Bag Filter, Cyclone, Multicyclone etc. The main function of the RAV is to lock the air and discharge the dust / powder. In the Bag Filter system there is negative pressure in the Bag Filter. So at the powder discharge point if there is any air leakage the powder will not fall down. So to restrict the leakage we provide the Rotary Airlock Valve. RAV consists of a stator & rotor. The radial & axial clearance is between 0.1 to 0.3 mm. The rotor has vanes (6 or 8) welded on the shaft. The rotor is mounted on the bearings at both the ends of the stator. A Geared Motor is provided to rotate the rotor. Since the clearance between rotor & stator is so low. Because of this air leak is very minimum and it delivers only powder.
Quality : Optimum
Grade : Industrial
Condition : New
Material : MS
Application : Industrial
Color : Blue
