Railway Circular Connectors

These JL5 Series Railway Circular Connectors are mode according to Ministry of Railway standard TB/T2716-1996. The connector's socket is covered with guided stainless sleeve and allows the connector to have the advantages of low contact resistance, long endurance, etc. The connection type between the plug and the receptacle is bayonet coupling with quick mating and easy use. This connector is widely used for the connection of electrical equipment of rail train. The plug or the receptacle may be mounted with both pins and sockets.
Technical Characteristics:
Temperature Relative Humidity Atmosphere Vibration Shock Endurance-55a i +125a 40A 2a Up to 90%i 95%101Pa-6.7Pa50i 2000HZi 294m/s240i 80strokes/mini 980m/s2500 cycles
This type is designed for the connection of railway, oil, and drilling machinery.Connect type is bayonet coupling.Owns many characteristics, such as well sealing, insulativity and simple operating.
Technical Characteristics:
Temperature -40 12316;55a C
Relative Humidity: 40A 2a C,relative humidity is up to 90% 95%
Height Above Sea Level: a 5000meters
Vibration: 10Hz-200Hz
Working Voltage: 380v
Working Current: 60A
Pressure-proof: 2800Vi ACi 50Hz
Shock: 10-40 strokes/min
Endurance: 1000 times
