Lider Electric Single Phase Mcb Panel - Maximum Output Current: 16 Ampere (Amp)

We are engaged in exporting excellent quality Pump Controller for 1 H.P Submersible Pumps-Single Phase- Model AcA A LTEMS 1050 to our valuable clients.
Pump Control Panel for Single Phase Water Filled Submersible Pumpset for starting and protection from overload.
Contactor provided for easy starting and stopping of Pumpset thus increasing the life of pumpset and pump controller.
Overload Protection device- Circuit Breaker Equipment provided to protect pump from over current.
Switching device- Miniature Circuit Breaker-M.C.B (C Series-inductive load) provided-for short circuit protection.
Many a time, it happens that, motor pump is left running even after our water tank on the roof is completely filled with water.We generally remain unaware of the overflow.
Start Capacitors provided for giving initial torque as per Horsepower of Motor Pump.
Run Capacitors provided as per Horsepower for smooth running of pumps and better life.
Start Button provided which charges and discharges the Start Capacitor.
Ammeters Provided with Brass nuts for measuring current consumed by motor pump.
Voltmeter Provided for measuring incoming voltages and can be read by pressing a switch for long life of voltmeter.
Single Lamp indication for showing motor pump running condition.

Please see chart for choosing correct rating control panel.
Colour : GREY
Voltage (volts) : 220~240 VAC, 50 Hz
Horsepower (HP) : 1 H.P
M.C.B Current Rating : 10
Run Capacitor Rating : 50
TYPE : SOLID
Current Carrying Capacity : 25
