Ptfe Push And Extruding Production Line

PTFE Push And Extruding Production Line This line is used for coating Ptfe jelly onto wire. It is composed of Mixer, Pre-former, Pushing & Extruding Machine, Sintering Furnace, Haul-off machine, Take-up with Traverser, Outer Diameter Measuring Device, Electrical Control Cabinet and Operation Desk, which can be divided into vertical and horizontal shapes. PTFE pipe Pushing and Extruding Machine is a derived product, whose difference is to push material in cylinder from top to bottom. The effective length of material cylinder has three sizes, 900, 1200, and 1800 mm. 900 and 1200 mm are for vertical machine, while 1800 for horizontal. Facing to the position of main machine, the sintering furnace can be arranged in upper part or at one side. One of the advantages of the latter is that it needs less building height (only 7 meters), furthermore, one baker can be added to increase productivity. The latter is good for making large sized wire. Technical Specifications Parameter Name Machine Type Type 900 Type 1200 Type 1800 Effective length of material cylinder 900mm 1200mm 1800mm Pushing and extruding motor 5.5kw 7.5kw 11kw Max pushing force 190KN 270KN 350KN Haul-off motor 1.5kw 1.5kw 1.5kw Pay-off motor 1.1kw 1.1kw 1.1kw Take-up motor 1.1kw 1.1kw 1.1kw Sintering furnace length 13m 15m 15m Sintering furnace power 40kw 45kw 45kw Line speed 0-20M/min 0-20M/min 0-20M/min Total height of the line 11500mm 12500mm 12500mm Platform height 2300mm 2900mm 3500 mm Layout dimensions 4000*2000 4000*2000 12000*2500 Material cylinder size (Together with the machine) 50,35, 28 or 60, 50, 40 75,50, 30 or 60, 50, 40 75,50, 30 or 80, 60, 40 Core pole size (Together with the machine) 16(6) 12(4) 16(6) 16(6) 20(8) Temperature increasing of sintering furnace <30min <30min <30min Pushing speed 10-50mm/min 10-50mm/min 10-50mm/min Recovery speed 500mm/min 500mm/min 500mm/min
