Power Brush Machine Zl 300

We are a very well known Exporter, Manufacturer & Supplier of Power Brush Machine ZL 300 in Bad Wunnenberg, North Rhine-Westphalia, Germany.

Features
a c Highest flexibility
a c Low investment costs
a c Up to 15 knots/min.
a c Programmable twist knot styles
a c Up to 200 brush programs

NC controlled semi-automatic twist knot machine with manual wire bundle and disk feeding. The operator turns the disk to the required hole, feeds the wire through the twisting head and disk and activates twisting by pressing the start button. Connection between the linear travel and the NC control of the twisting drive is made by an absolute position encoder. This means twisting at different speeds and forces over the single knot length to make good quality rose end knots or cable twists. The control system can store up to 200 programs for different kinds of brush types. A wire picker is optionally available.
