Pepperl + Fuchs Smart Current Driver Kfd2-scd2-ex1.lk

Price:

Get Latest Price

Brand Name :

Pepperl + Fuchs

In Stock

Product Specifications

Rated Current	20 mA max
Noise Level	< 1 mV
Output Type	Other, 2-wire, 4 mA ... 20 mA analog current driver
Features	Smart diagnostics, line fault detection, high accuracy, plug-in connection
Working Temperature	-20AdegC to +60AdegC
Application	Intrinsic safety applications, process automation, analog signal transmission
Phase	Single Phase
Power Supply	24 V DC (nominal)
Output Current	4 mA to 20 mA
Operating Temperature	-20AdegC to +60AdegC
Current Range	4 mA to 20 mA
Rated Power	Up to 650 mW depending on load
Connector Type	Screw terminals
Cooling Method	Natural air convection
Power Factor	Not applicable for DC device
Product Type	Smart Current Driver
Output Power	Up to 650 mW (depending on field device load)
Output Frequency	DC, not applicable
Input Voltage	20 V DC to 35 V DC
Voltage Protection	Reverse polarity protection and surge protection
Efficiency	Typically above 80%
Material	Polycarbonate housing
Line Regulation	< 0.01 % of output range
Storage Temperature	-40AdegC to +80AdegC
Weight	Approx. 150 g
