Om9385-11 Power Amplifier Module With Integrated Duplexers

OM9385-11 is a multi-mode, high efficiency Low Band, Mid Band and High Band PAMiD (Power Amplifier Module with integrated Duplexers) module designed for use as the integrated RF front-end in multi-mode NR / LTE / UMTS / CDMA mobile cellular equipment. The high efficiency PAMiD contains power amplifier paths for 3G/4G/5G Low, Mid and High Band frequencies along with distribution switches, multiplex filters, and antenna switches for multi-band coverage of both transmit and receive functions. OM9385-11 band select and operating parameters are programmed through the Mobile Industry Processor Interface (MIPI) bus(es). The OM9385-11 transmit-receive module supports Average Power Tracking (APT) for application versatility combined with higher system efficiency across a wide range of power levels. The OM9385-11 is packaged in a RoHS-compliant, compact 62-pin, 6.5 8.6 0.8 (max) mm surface-mount leadless package.
