Measurement Of Level By Air Purge Method Apparatus - Transparent Acrylic Tank (150mm X 600mm), Pressure Gauge In Mmwc, Air Regulator Valve | Versatile Level Measurement System For Engineering Testing
Price:
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Edutek
In Stock
Product Specifications
| Interface Type | Analog (no digital interface) |
| Temperature | 5AdegC to 45AdegC operating range |
| Test Range | 0-300 mm (level measurement) |
| Equipment Type | Level Measurement Apparatus |
| Features | Simple operation, corrosion-resistant, transparent measuring tube, regulated air flow system, pressure regulator with gauge, easy maintenance |
| Usage | Engineering Testing Equipment |
| Measuring Range | 0 to 300 mm |
| Response Time | Instantaneous (upon air purging) |
| Max Height | 300 mm (liquid column) |
| Operating Voltage | 230 V AC |
| Port Size | 6 mm (air inlet) |
| Product Type | MEASUREMENT OF LEVEL BY AIR PURGE METHOD APPARATUS |
| Number of Specimens | 1 at a time |
| Application | Engineering Testing Equipment |
| Specimen Size | Up to 150 mm width |
| Humidity | Up to 85% RH |
| Power Supply | 230 V AC, 50 Hz |
| Gas Pressure | 0.5aEUR"1.0 kg/cmA2 (using laboratory air) |
| Resolution | 1 mm |
| Display Type | Graduated scale |
| Frequency | 50 Hz |
| Automation Grade | Manual |
| Accuracy | A+-1 mm |
| Mounting Type | Benchtop |
| Capacity | 1 measuring vessel per test |
| Machine Weight | Approx. 10 kg |
| Test Speed | Manual |
| Test Width | 150 mm |
| Test Stroke | Up to 300 mm |
| Control Mode | Manual/Analog |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
Product Overview
Key Features
MEASUREMENT OF LEVEL BY AIR PURGE METHOD APPARATUS
Salient Features:
The EDUTEK Level Measurement by using Air Purge systems is a versatile and standalone system useful for demonstrating the indirect measurement method of measuring level of water in mmwc.
The unit consists of a transparent cylindrical tank, calibrated pressure gauge in mmwc, air regulating valve, etc. all mounted on a powder coated platform. Air supply should be provided by the user.
Comprehensive instruction manual complete with theory and operating details is provided along with the unit.
Technical Specifications
Level Tank: Transparent, () 150mm x (H) 600mm
Pneumatic Tubing: 1/4. PU
Level Indicator: Pressure gauge calibrated in mmwc.
Air Regulator: 1/4 air regulating valve, leak proof.
Experiments:
Study of Level measurement using back pressure.
Demonstrate the implicative use of pressure gauge as level measurement (indirect measurement technique).
