Md4115 Sop8 5.0w Single Sound Channel

Supported by vast business knowledge, we are indulged in supplying of MD4115 SOP8 5.0W Single Sound Channel in Shenzhen, Guangdong, China. These offered products are manufactured using supreme grade quality components that is sourced from reliable vendors of the market keeping in mind set industry norms. Tested on various quality parameters, to deliver the quality approved range for our respected customers at nominal market price.

Features:

Output power
PO at 10% THD+N, VDD = 5.5V
RL = 2 ohms 5.1W (typ)
RL = 4 ohms 3.0W (typ)
PO at 1% THD+N, VDD = 3.6V
RL = 2 ohms 2.38W (typ)
RL = 4 ohms 1.95W (typ)
Original AERC technology, providing excellent full bandwidth EMI suppression
Excellent "POP-NOISE" noise suppression ability
Working voltage range:2.5V to 6V
Filter-free class D structure
High efficiency up to 90%
High power supply rejection ratio (PSRR): 80dB below 217HZ
Fast start time (40ms)
Low static current (4mA)
Low off current (<0.1 mu A)
Overcurrent protection, short circuit protection and overheating protection
RoHS compliant and 100% lead(Pb)-free
Application
USB sound boxa Portable speakers
PMP/MP4/MP5 player
GPS
Digital photo frame
