Long Range Antenna Pa Lna Sma 2.4ghz Wireless Transceiver Module - Plastic 18mm X 30mm Compact Size | 2mbps Speed 1000m Range 125 Channel Capacity

Nrf24l01L wireless module use NRF24l01 IC from Nordic work at 2.4Ghz worldwild open ISM band working data speed up to 2 Mbps 125 channel can reach multiple channel and jumping channel needs operation voltage 3.3-3.6V transmit power up to 20 dBm then sensitivity can reach -86dbm at 2 Mps high speed.

This module is designed for long distance as well as high speed transferring pins and interface are fully compatible with normal NRF24L01+ module no need extra control pins. (two extra pins without silk print can connect to GND)

Compact size easy to use simply extend the communication distance.

FEATURES OF MODULE:
Voltage 3-3.6v (recommended 3.3v) V
+20 DBm maximum output power
Emission mode operating current (peak) 115 MA
Receive mode operating current (peak) 45 MA
Power-down mode current 4.2 UA
Operating temperature -20 A C
Receiving the Spirit of 2Mbps mode -92 dBm
Receiving the Spirit of 1Mbps mode -95 dBm
Receiving the Spirit of 250Kbps mode -104 dBm
PA gain of 20 dB
LNA gain of 10 dB
Coefficient of 2.6 dB LNA voice
Antenna gain (peak) 2 Dbi
APPLICATION:
Wireless remote control somatosensory equipment
Active RFID NFC
Smart grid smart home
Wireless Audio
FEATURE OF NRF24L01:
2.4Ghz worldwide free open ISM band
High working speed up to 2Mbps high efficient GFSK modulation can transfer audio or video.
125 channels for multiple communication or jumping channels communication.
Embedded CRC error-check and point to mutiple point communication control
operation voltage at 3.0-3.6V (3V3)
External 2.4Ghz antenna compact size 18mm * 30mm
Module can set address by software only output data when device receive right address can directly connect to any MCU and easy to programmer.
2.54 pins space compatible with normal module interface easy to replace.
51 AVR reference code is available simply copy and modify
Transfer distance can reach 1000 meters @ 250 Kbps (normally can reach 0.8KM)
