Led Video Screen Assembly Pick And Place Machine

With a motive of delivering qualitative products, we are instrumental in manufacturing, exporting and supplying a world class range of LED Video Screen Assembly Pick And Place Machine in Guangdong, Guangdong, China.

1.The high-rigidity,high-accuracy and high-stability rack
1)Base and Y axis are made by integrated design?X axis uses the high-hardness aluminium alloy and is suppressed into shape by a molding machine.
2)X axis is completed at one time by a large special equipment. Every parts and installation planes of base and Y axis are assembled exactly to ensure high precision.
3)Fast assembling to avoid deformation.
2.High-speed, high-precision and long-life X/Y axis
1)Rolling guides used on X/Y axis are imported from Japanese brand THK, which has low noise and high precision.
2)The linear motors used on X/Y axis are made by Japanese company Sanyo, which is exclusively used in Pick&&Place machine.
3)The grating ruler with high resolution is imported from Britain company Renishaw, which ensures the high precision of X/Y axis motion.
3.The high-speed and high-precision head
1)The parts and base of head are made by aviation-grade aluminum, which makes the head more stable and reliable.
2)Adapting Japanese micro servo motor and IKO guide rail, which ensures the up-down of Z axis in high-speed, high-accuracy, and high stability.
3)High-precision ball spline ensures the high-accuracy of rotation.
