Black & White High Precision Pcb Assembly Placement Machine

By monitoring the development of the market, we are betrothed in manufacturing, exporting and supplying an exclusive array of High Precision PCB Assembly Placement Machine in Guangdong, Guangdong, China.

1.The high-rigidity,high-accuracy and high-stability rack
1)Base and Y axis are made by integrated design?X axis uses the high-hardness aluminium alloy and is suppressed into shape by a molding machine.
2)X axis is completed at one time by a large special equipment. Every parts and installation planes of base and Y axis are assembled exactly to ensure high precision.
3)Fast assembling to avoid deformation.
2.High-speed, high-precision and long-life X/Y axis
1)Rolling guides used on X/Y axis are imported from Japanese brand THK, which has low noise and high precision.
2)The linear motors used on X/Y axis are made by Japanese company Sanyo, which is exclusively used in Pick&&Place machine.
3)The grating ruler with high resolution is imported from Britain company Renishaw, which ensures the high precision of X/Y axis motion.
3.The high-speed and high-precision head
1)The parts and base of head are made by aviation-grade aluminum, which makes the head more stable and reliable.
2)Adapting Japanese micro servo motor and IKO guide rail, which ensures the up-down of Z axis in high-speed, high-accuracy, and high stability.
3)High-precision ball spline ensures the high-accuracy of rotation.
