Laser Cutting And Engraving Machine (Rf-5030-co2-50w)

We are engaged in offering excellent quality Laser Cutting and Engraving Machine (RF-5030-CO2-50W) to our valuable clients.
Performance:
1. Applicable materials:-
plastic, wood, jade, crystal, rubber, plexiglass and other non-metal materials.
2. Applicable industry : Mainly used for the engraving and cutting of little artistic works. such as engraved portraits, badges, breast cards and various engraved packages etc..
3. Technical parameters:-
Laser power : 50W(optional) equip with red dot on the laser head
Laser type: Hermetic CO2 glass tube
Power supply: AC220V 50 HZ/AC110V 50 HZ
Working table
up/down working table
Working area: 500mmx300mm
Max moving speed: 1500mm/s
Locating precision: <0.01mm
Min shaping character:
Character:2x2mm,letter:1x1mm
Operating temperature: 5-35 degree
Resolution ratio: 4500dpi
Control configuration: DSP
Data transfer interface: USB(offline)
System environment: WINDOWS 2000/WINDOWS XP
Cooling way: Water cooling and protection system
Graphic format supported: BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,etc
Compatible software
Corel-Draw, Auto-CAD
Cutting thickness : 0-10mm(depends on different material)
Color separation
Separation of cutting up to 256 colors
Sloping engraving
Yes, slope can be designed discretionarily
Cuts off the water supply the protection : yes
Net weight : 70kg
Packing : Plywood case

Clients can avail this Laser Cutting and Engraving Machine (RF-5030-CO2-50W) at industry leading prices from us.
