Ies 1050 A 5-port 100m Unmanaged Industrial Ethernet Switch

Brand: San Telequip
Area Network Type: LAN Capable
Model Name/Number: IES 1050 A
Model Number: IES 1050 A
Country of Origin: Made in India
Weight: 600 gm
Protocols: IEEE802.3, IEEE802.3u
Input Power Supply: Wide DC power input (12V/24V/48V) with 7.62mm industrial power terminal
Full Load Consumption: Less than 3.36W (@24VDC)
Ethernet Standard: 100BaseT(X) speed Auto-Negotiation, Full/Half Duplex mode, MDI/MDI-X connection
Fiber Port: 0BaseFX100M Full Duplex SC port (with FC/ST options), max distance to 120km
Tx Power: -6 to -10 db
Rx Sensitivity: -34 dB
Forward Mode: Store-and-Forward
Switching Bandwidth: 1.6 Gbps
Cache Size: 448Kbits
MAC Address Table: 1K
Working Temperature: -40 to +85 Degrees C
Humidity: 5 to 95 % RH (non condensing)
Dimensions: 60.2 x 138.5 x 109 mm
Housing: Metal, IP40 protection
Installation: Wall mounting or DIN rail mounting
MTBF: 432500h
