Iec 61000-4-5 High Voltage Surge Generator Up To 8kv
Price: 5500 USD / Set
Get Latest Price
Minimum Order Quantity :
1 Set
In Stock
Product Specifications
| Voltage | 6kV |
| Compliance | IEC 61000-4-5 |
| Display | Touchscreen |
| Interface | RS232/USB |
| Programming | Programmable |
| Self-Test | Built-in |
| Usage | Simulates power line surges for testing device's performance against high energy disturbances. |
| Features | IEC 61000-4-5 Compliant, Touchscreen Display, Multi-language Support, Programmable Operation, Self-Calibration, PC Control, Surge Simulation |
| Color | Grey |
| Power Supply | AC 220V 50/60Hz |
| Material | Mild Steel |
| Product Type | IEC 61000-4-5 High Voltage Surge Generator up to 8kV |
| Application | Industrial Use |
| FOB Port | FOB Shanghai |
| Payment Terms | Paypal, Telegraphic Transfer (T/T), Western Union, Cash Advance (CA), Cash in Advance (CID) |
| Supply Ability | 3000 Per Year |
| Delivery Time | 1 Week |
| Sample Available | No |
| Sample Policy | Contact us for information regarding our sample policy |
| Packaging Details | export standard packing, wooden case/pallet |
| Main Export Market(s) | Asia, Australia, Central America, North America, South America, Eastern Europe |
| Main Domestic Market | All India |
| Certifications | ISO 9001, CE, Ilac-MRA, CNAS accredited calibration certificate |
Product Overview
Key Features
Surge
pulses occur due to direct or indirect lightning strokes to an external
(outdoor) circuit. Another source for surge pulses is switching transients
originating from switching disturbances and systems faults. This leads to
currents or electromagnetic fields causing high voltage or current transients.
The energy is particularly large. And the impact on the product might be
destructive. A lightning surge generator is used to evaluate the performance of
device subjected to high energy disturbances from the power line port and other
signal line ports. Our surge generators simulate these disturbances for all the
necessary voltage levels in accordance with IEC/EN 61000-4-5.
Compliant standard
l IEC/EN 61000-4-5: Testing and
measurement techniques Surge immunity test
l UL 1449: Standard for Surge
Protective Devices
Features
l User friendly 7 touch panel
display
l Support multi-language &
facilitate users
l Built-in environment self-test
program
l Built-in international standard
test levels make it more user friendly (pre-programmed IEC 61000-4-5 test
settings)
l EUT intelligent detection
l Self-calibrate function to ensure
equipment normal operation
l RS232/USB interface, for PC control
operation & printable test report
Technical data
Model | SUR S8C |
Surge waveform | Open-circuit voltage Short-circuit current wave: 8/20s |
Open-circuit voltage | 0.2~8kV |
Short-circuit | 0.1~4kA |
Polarity | Positive/negative/alternating |
Phase | 0~359 synchronous, asynchronous, |
Effective output impedance | Differential impulse |
Coupling/decoupling | Built-in, single-phase three-wire, 16A (Customer specific on demand) |
Coupling mode | Differential |
Number of surges | 1~9999 |
Interval | 10~9999s |
Power supply | AC |
Ambient temperature | 15~35 |
