Hydraulic Excavator By Gmmco Limited

Since 1967, we are involved in suppling Hydraulic Excavator. Widely demanded in manufacturing unit, repairing centers and warehouses, this excavator is extensively used for digging and mining. In order to manufacture the provided excavator in adherence with set industry standards, vendors ingenious professionals utilize premium quality components and sophisticated techniques. Also, this Hydraulic Excavator can be availed from us at an affordable price range within the committed time span. Features:   Excellent mining and digging Easy to operate Corrosion resistance body Energy efficient Overview The 320D/D L Series 2 incorporates innovations to improve your job site efficiency through low owning and operating costs, excellent performance, and high versatility. Engine Units: Engine Model Cat C7.1 Net Flywheel Power 106.0 kW Bore 105.0 mm Stroke 135.0 mm Displacement 7.01 L Engine Power - ISO 14396 112.5 kW Net Power - SAE J1349 106.0 kW Weights Operating Weight 22390.0 kg Operating Weight (ISO 6016): Long Undercarriage - Maximum Operating Weight 22390.0 kg Operating Weight (ISO 6016): Long Undercarriage - Minimum Operating Weight 21680.0 kg Operating Weight (ISO 6016): Standard Undercarriage - Maximum Operating Weight 21690.0 kg Operating Weight (ISO 6016): Standard Undercarriage - Minimum Operating Weight 21040.0 kg Operating Weight - Long Undercarriage 21 680 kg-22 390 kg (47,800 lb-49,360 lb) Operating Weight - Std. Undercarriage 21 040 kg-21 690 kg (46,390 lb-47,820 lb) Service Refill Capacities Fuel Tank Capacity 410.0 L Cooling System 25.0 L Engine Oil 22.0 L Final Drive (each) 8.0 L Hydraulic System (including tank) 260.0 L Hydraulic Oil 138.0 L Swing Drive (each) 8.0 L Swing Mechanism Swing Speed 10.9 RPM Swing Torque 61.8 kNm Drive Maximum Drawbar Pull 205.0 kN Maximum Travel Speed 5.4 km/h Hydraulic System Pilot System - Maximum Pressure 3900.0 kPa Boom Cylinder - Bore 120.0 mm Boom Cylinder - Stroke 1260.0 mm Stick Cylinder - Bore 140.0 mm Stick Cylinder - Stroke 1504.0 mm B1 Bucket Cylinder - Bore 120.0 mm B1 Bucket Cylinder - Stroke 1104.0 mm Main System - Maximum Flow (Total) 404.0 L/min Maximum Pressure - Equipment 35000.0 kPa Maximum Pressure - Equipment (Lift mode ON) 36000.0 kPa Maximum Pressure - Swing 25000.0 kPa Maximum Pressure - Travel 35000.0 kPa Pilot System - Maximum Flow 32.4 L/min (1,977 in3/min) Swing System - Maximum Flow 202.0 L/min
