Hermle C600u 2 Cnc Machining Center

Control system:
a Heidenhain iTNC 530
a Control ON-hours: 66636
a Machine ON-hours 80156
a Spindle ON hours: 12412

Spindle:
a Speed: 16.000 1/min
a Tool holder: SK-40
a 300 tool positions

Equipment:
a Rigid clamping table
a NC reversible clamp iTNC
a Standard coolant unit
a Chip conveyor
a Closed cabin roof section
a Electronic thermal expansion compensation (iTNC)
a Electronic manual control module (iTNC)
a Tool breakage monitoring
a Chip flushing gun
a Foot switch for clamping/unclamping
a Hydraulic unit 200 bar for clamping/unclamping

Travel paths:
a X-axis (longitudinal): 600 mm
a Y-axis (transverse): 450 mm
a Z-axis (vertical): 450 mm

Table:
a Clamping surface: 800 mm x 465 mm
a Maximum table load: 250 kg

Axes:
a Axes in motion: 35 m/min
a Acceleration: 5 m/sA
a Measuring system X/Y/Z: 0.1 Aum

Dimensions & weight:
a Machine weight: approx. 6.8 t
a Machine dimensions (W x D x H): 2.5 m x 2.4 m x 2.43 m

The machine can be inspected under power by appointment.
