Fxc-412cd Die Board Laser Cutting Machine

We are engaged in offering excellent quality FXC-412CD Die Board Laser Cutting Machine to our valuable clients.
Model: FXC-412CD
Laser Power: 400W laser
Worktable Size: 1250mm*1250mm

Special characteristics of the product:
Cutting Capacity
Die-board: 18-20mm; Mild Steel: 2mm; Stainless Steel: 1mm

1)400W laser tube, perfect beam of light quality and efficiency
2)Open can use, no start machine fare, low consumption
High quality ball screw& linear guide transmission system
3)Driving system imported from Mitsubishi / Panasonic in Japan
4)Auto-following system
5)Special smoke ventilation system that effectively remove smokes and dusts.
6)Scientific assembly to insure machine high precision and performance
7)Machine mainly movement parts made by Cast-aluminum, to insure machine working at high speed and stable.
8)Light-duty design ,Save floor space

Parameters:-
Model : FXC-412CD
Laser output power : 400W laser
X-axis travel-length : 1250mm
Y-axis travel-length : 1250mm
Positioning Precision : A 0.05mm/m
Max. speed of positioning : 10m/min
Controlling system : Movement control card/NC
Transmission system : Ball screw & Linear guide
Driving system : 3 Axial servo
Optical system : Semi-optical
Moving structure : Gantry
Chiller system : Special Chiller system for imported laser tube
Overall dimensions (LA WA H) : 2350mmA 2100mmA 1400mm
Weight : 800KG
Structure : Open
Power supply : 220V /50HZ/30A
