Elevator Load Monitoring Sensors

We are highly proficient trader and supplier of an unmatched quality range of Loadcell For Elevators in Jalandhar Punjab India available with following details.

Specifications:

Standard Capacities 80-Kgf
Excitation Voltage 10VDC-Max. 15VDC
Normal Output 2.0 mV/V
Non - Linearity < i? 0.025% FSO
Hysteresis < i? 0.02% FSO
Non - Repeatability < i? 0.01% FSO
Creep (30 minutes) < i? 0.03% FSO
Zero balance i? 1.0% FSO
Input Resistance 400 i? 15 Ohms
Output Resistance 350 i? 5 Ohms
Insulation Resistance (50VDC) > 1000 Mega Ohms
Cable Length (4 Core Screened) 45Cm.
Safe Overload of Related Capacity 150%
Ultimate Overload of Rated Capacity 200%
Temp Compensated Range 0-60i? C
Temprature Effect on Output < 0.0015% FSO/i? C
Temprature Effect on Zero < 0.0020% FSO/i? C
Platter Size 300mm x 300mm
Eccentric Load Effect < 0.02% of FSO at 1/3 rated load placed within the specified sized platter
Deflection <0.5mm at FSO
Tightening Torque 2 m.Kg
Finish & Construction Alluminium Alloy
Environmental Protection Class lp65
Applications Bench Counting Postal Scales Check Weighers
