Dc2248 Coreless Brushless Motor

DC2248 Coreless Brushless Motor a Extreme Speed Series | COSMOTR (COSTR Motion)

KEY SPECIFICATIONS:
- Nominal Voltage: 24V
- Nominal Speed: 53,500 rpm (ultra-high speed)
- Max Continuous Power: 80W
- Max Efficiency: 88%
- Torque Constant (Kt): 4.25 mNm/A
- Mechanical Time Constant: 5.7 ms
- Diameter: A 22 mm
- Length: 65.8 mm
- Weight: 99.5 g
- IP Rating: IP54
- Operating Temperature: 25a 30A C ambient

CORELESS DESIGN ADVANTAGES:
- Zero iron-core cogging for ultra-smooth rotation
- Extremely fast acceleration (5.7ms mechanical time constant)
- Exceptional efficiency at high RPM
- Minimal electrical noise and EMI
- High power density in compact form factor

APPLICATIONS:
- Aerospace and UAV systems
- Medical devices (surgical tools, dental equipment)
- Precision instruments and laboratory equipment
- High-speed spindles
- Consumer electronics requiring silent, fast motors

BRAND: COSTR Motion | COSMOTR GLOBAL TECHNOLOGY SOLUTIONS PTY LTD
ORIGIN: Australia | CERTIFICATIONS: ISO 9001:2015
CONTACT: | +61 450 651 026
