Curved Tempered Glass By Qingdao Sunny Glass Co.,ltd.

Following are the main specifications of Curved Tempered Glass:
Max.Size 5300*2440(mm)
Min Size 400*300(mm)
Thickness 5-19(mm)
Min.benting Radius 5-6(mm) R1000 8-12(mm) R1200 15-19(mm) R1800

Hot curved glass, which is made of float glass, is firstly heated to softening point on metal mould and then bent to shape by weight of glass itself and outside force, then finally cooled down.

Hot curved tempered glass/bent glass adopts the similar process with tempered glass, but before the cooling process, using the external power to bend glass to a proper radian according the requirement. The wind pressure resistance of hot curved tempered glass/bent glass is better than flat tempered glass and other kinds glass for the special shape.

Applications:
Hot curved glass is used in curtain wall with curved structure, skylight, sightseeing elevator, hyperboloid and taper shaped buildings.
Hot curved glass/bended glass/bent glass is widely used in esthetics architecture field for beautiful appearance.

Hot curved glass/bended glass/bent glass is extensively used in shower door glass, fencing glass, revolving door glass, high quality furniture glass and architectural situations
