Computerized Micro Vickers Hardness Tester (Ht-1000a With Vidas 2.0) - Dimension 530x200x530mm, 35kg | 10x Manual Eyepiece, Halogen Illumination, 5 Mp Usb Camera, Auto Turret Mechanism, Emergency Switch
Share

Computerized Micro Vickers Hardness Tester (Ht-1000a With Vidas 2.0) - Dimension 530x200x530mm, 35kg | 10x Manual Eyepiece, Halogen Illumination, 5 Mp Usb Camera, Auto Turret Mechanism, Emergency Switch

Price:

Get Latest Price

Minimum Order Quantity :

1 Number

Brand Name :

Computerized Micro Vickers Hardness Tester

In Stock

In Stock

Product Specifications

Test Range5 gf to 1000 gf (Micro Vickers)
Automation GradeFully Automatic with VIDAS 2.0 software
Specimen SizeUp to 95 mm wide, max 100 mm high
Dimension (L*W*H)530X200X530
ApplicationPrecision hardness measurement of micro-components, metals, and alloys
Max Height100 mm (specimen mounting height)
Temperature10AdegC ~ 35AdegC (operation)
HardnessMicro Vickers (VHN/HV)
Resolution0.01 I1/4m (via digital eyepiece and camera)
Port SizeStandard USB and serial ports (for data transfer and control)
Humiditya%0$?85% RH
FeaturesAutomated loading, image analysis, data logging, auto-turret, high-precision optics
Display Type7 Color LCD and PC-based graphical interface
Response Time< 1 Second (measurement readout)
AccuracyA+-1.0% of full scale
Interface TypeUSB, RS232
Mounting TypeBench-top
Power SupplyAC220VA,A+-5% 50-60Hz
Measuring Range1 HV ~ 2967 HV
Operating Voltage220V AC
Frequency50/60 Hz
Number of SpecimensSingle specimen per test cycle
Equipment TypeComputerized Micro Vickers Hardness Tester
UsageLaboratory materials analysis
Capacity1000 gf Max test force
Machine Weight35 Kilograms (kg)
Test SpeedCustomizable according to VIDAS 2.0 software setting
Test WidthUp to 95 mm (as per standard specimen stage)
Test StrokeUp to 60 mm
Control ModeFully Computerized
Payment TermsCheque, Telegraphic Transfer (T/T), Others
Supply Ability1 Per Day
Delivery Time1 Week
Main Domestic MarketAll India

Product Overview

Key Features

Halogen illumination unit gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

Company Details

TRUEMET by Om Engineering Instruments: Your Trusted Partner in Material Testing and Metallurgical Solutions

OEI is the leading Manufacturer, Supplier, and Exporter of various ranges of Material Testing Machines and Metallurgical Equipment under the brand TRUEMET. With a commitment to excellence and a relentless pursuit of quality, we have established ourselves as a trusted partner for industries seeking reliable and accurate solutions for their testing and analysis needs.

Our material testing machines, including Hardness Testing Machines and Universal Testing Machines, are designed to meet the highest standards of precision and performance. Each machine is meticulously engineered and can be computer-controlled, ensuring precise and repeatable results. Whether it’s evaluating the hardness of a material or conducting a comprehensive mechanical analysis, our TRUEMET machines provide the reliability and accuracy that businesses can trust.

In addition to our exceptional material testing machines, TRUEMET also offers a range of advanced metallurgical equipment. Our Metallurgical Microscopes, equipped with Truemet metallographic image analysis software, empower researchers and engineers to explore the intricate details of material structures with unmatched clarity and precision. Furthermore, our Weld penetration inspection software, TrueWeld, ensures the integrity and quality of welded joints. Additionally, our Sample Preparation Equipment streamlines the process of specimen preparation, enabling efficient and accurate analysis.

At TRUEMET, we are committed to delivering solutions that empower businesses to make informed decisions based on reliable data. With our state-of-the-art equipment, advanced software, and a team of dedicated professionals, we strive to provide unmatched customer satisfaction and technical support.

We are constantly expanding our after-sales activities including Installation, Calibration, and Repair Services. For both our repair and calibration services we aim for the shortest possible turnaround times.

Experience the precision, reliability, and innovation that TRUEMET brings to the world of material testing and metallurgical solutions. Partner with us and unlock a new level of confidence in your testing processes.
