Computer Controlled Load Cell Based Vickers Hardness Tester (Tht-a Series With Vidas 4.0) - 585x200x630 Mm, 42 Kg | Halogen Illumination, Lcd Display, Dual Optical Channel
Share

Computer Controlled Load Cell Based Vickers Hardness Tester (Tht-a Series With Vidas 4.0) - 585x200x630 Mm, 42 Kg | Halogen Illumination, Lcd Display, Dual Optical Channel

Price:

Get Latest Price

Minimum Order Quantity :

1 Number

Brand Name :

Vickers Hardness Tester

In Stock

In Stock

Product Specifications

Power SupplyAC220VA+-5% 50-60Hz
Automation GradeFully Automatic
Interface TypeUSB / Ethernet
Measuring Range1HV aEUR" 2967HV
Response Timea%0$?3 seconds per indent
Resolution0.1 I1/4m
Port SizeStandard USB / Ethernet for PC connection
Humiditya%0$?85% RH
Dimension (L*W*H)585X200X630 Millimeter (mm)
HardnessVickers (HV)
Number of SpecimensMultiple via automated positioning
Frequency50-60Hz
Temperature10AdegC ~ 40AdegC
Display TypeHigh-definition touchscreen display
Mounting TypeBenchtop
Max Height160 mm
Operating VoltageAC220V A+-5% 50-60Hz
Equipment TypeVickers Hardness Tester
AccuracyA+-1%
ApplicationMetals, alloys, ceramics, surface coatings
Specimen SizeUp to 120 mm width, max height 160 mm
Test Range5HV aEUR" 2900HV
FeaturesLoad cell based, PC controlled, automatic turret, image analysis, data storage, motorized stage, auto measurement
UsageVickers hardness measurement
CapacityLoad cell selectable: 10g to 1kg
Machine Weight42 Kilograms (kg)
Test SpeedVariable, computer controlled
Test WidthUp to 120 mm
Test StrokeMax 90 mm
Control ModeComputer Controlled via VIDAS 4.0 software
Payment TermsCheque, Telegraphic Transfer (T/T)
Supply Ability1 Per Day
Delivery Time1 Week
Main Export Market(s)Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic MarketAll India

Product Overview

Key Features

Equipped with auto turret mechanism. Auto turret perform a series of operation and measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched using keypad.
