Cnc Gear Hobbing Liebherr Lc 502

Our organization have been actively engaged in manufacturing, exporting, distributing and supplying a premium quality CNC Gear Hobbing LIEBHERR LC 502 in Ferrara, Emilia-Romagna, Italy.

Make : LIEBHERR Model : LC 502

a c Max. Wheel Diameter : 500 mm
a c Gear Width : 400 mm
a c Max. Module : 10
a c Table Diameter : 420 mm
a c Table Hole : 150 mm
a c Distance Hob Workpiece Axis : 40-340 mm
a c Max. Distance Table - Midth of Hob Spindle : 575 mm
a c Max. Distance Table - Outer Steady : 825 mm
a c Tangential Movement of Hob : 200 mm
a c Diameter of Hob : 170 mm
a c Max. Cutter Length : 230 mm
a c Milling Tool Taper: SK 40 Milling Head Swivable : +/- 50 deg.
a c Feeds Axial : 0,1-20 mm/WU
a c Radial Feed : 0,1-4 mm/WU
a c Tangential Adjustment : 0,01-5 mm/WU
a c Rapid Travel X/Y/Z : 2000/3000/1000 mm/min
a c Hob Turning Speeds : 36-460/48-480/72-720 U/min
a c Total Power Requirement : 55 kVA Approx.
a c Weight of Machine : 10 tons approx.

MACHINE IS EQUIPPED WITH :
Hob Arbor
Hydraulic Work Clamping
180 deg. Swing Arm Auto Loader Chip Conveyor
Hydraulic Chiller
Full Splash Guard
Torit Mist Collector
Panel Air Conditioner
