Ceiling Fan Winding Machine - Kij 113 - Color: Red

Ceiling Fan Stator Rewinding Machine - KIJ 113

* Price is given with Courier + GST

* Home Delivery (Company will be responsible for delivering the machine to your home)

* KIJ-113 is an electric powered model. It comes with an electric brake system.

* It has the facility of fixed die. It takes only 10 seconds to apply the die.

* You can choose either Master die or Multi die as an option.

* HP (186.5 Watts) Inverter compatible In case of no electricity, you can easily run the machine on inverter (single battery) for 3 to 4 hours.

* It comes with a 5+5 digit meter which has a warranty of 7 years.

* The warranty on the die is 15 years. (For rusting or peeling of polish on the die)

* Motor Warranty : 1Year

* All our models are noise and vibration free.

* In this model, you have been given a small locker box to keep your belongings in which you can keep the die of your machine or any of your tools.

* If you face any problem in operating the machine, you can call the company's helpline number for assistance.

* Kisan Engineering is the only company in India that manufactures all the parts of the machine itself. You can also visit the company and buy the product.

* Weight : 48 kg (With Packing 55.5 Kg)

* Winding Type Aluminum & Copper

* Wire Gauge : 27 to 38 SWG

* Voltage : 240V

* Speed : 1440 RPM

* Winding Direction Anti Clock, Clock wise

* Dimensions Length : 33.5 Inch, Width 13.5 Inch, Height 22 Inch)

* Stator Width : 9 mm to 45 mm

* Stator Length : 190 mm Maximum
