Carbon Monoxide Gas Sensor Transmitter With Analog Output Humidity: 15 To 90%rh

We are praised brand for Manufacturing, Exporting, Distributing and Supplying Carbon Monoxide Gas Sensor Transmitter With Analog Outputs in Jaipur, Rajasthan, India.

Product Features:
* Fully sealed sensor cell with gas-specific gel
electrolyte and hydrophobic filter.
* High accuracy, selectivity and reliability with low
calibration drift over time.
* Long operational lifespan compared to solid state
semiconductor sensors.
* Simplified maintenance via exchange of pre-calibrated
sensor cartridges or easy on-site calibration.
* Power supply input is diode-protected against reverse
voltage with anti-poisoning and over-flooding protection.
* Fast tool-free wire termination via the supplied terminal block.
* Supplied with shipping cap to protect sensor during transport .
* Various housing options available (IP44, IP65/NEMA 4X ), duct mounting kit also available.

Power supply +16 - 29 VDC with reverse polarity diode protection
Power consumption 22mA max. (0.5VA @ +24VDC)
Analog signal output Linear proportional 4-20mA current loop
Output load a 500 a for current signal
Sensor Performance
Sensor element type Electrochemical
Detected gas Carbon Monoxide (CO)
Measurement range 0-300 ppm
Accuracy A 3 ppm
Resolution 0.5 ppm
Repeatability < A 5% FS
t90 Time a 50 seconds (response time a 30 seconds)
Zero-point variation A 4 ppm
Zero/Gain calibration drift < A 0.4% FS signal per month
Sensor Life Time >6 years (with recommended calibration interval)

Storage time 6 months @ 5 a 30 A C
Operating temperature range -15 A C to +50 A C
Humidity range 10-95% RH (non-condensing)
Pressure range Atmospheric A 20%
Wiring 2 Wire
Wire Connection Spring loaded terminal min 0.25 mm2
to max 2.5 mm2
Mounting Wall mounting
Relative Gas Density 0.97 (Air=1)
Mounting Height 1.5 m to 1.8 m
Recommended Coverage Area 465 m
2
to 930 m
2
, ideal condition assumed
Dimensions (sensor cartridge only) 38 mm (L) x M25 mounting diameter
Weight (sensor cartridge only) 30 g
Sensor Cartridge Polycarbonate IP65
Optional Housings Specifications: F: ABS, IP44, UL 94: V0, weight: 0.1 Kg
D: Polycarbonate, IP65, UL 94: V2, weight: 0.15 Kg
K: D Housing with Duct Kit, weight: 0.1 Kg
