Capacitive Level Sensor For Conductive Liquids Accuracy: +-2% %

We are Manufacturing, Exporting, Distributing and Supplying Capacitive Level Sensor for Conductive Liquids in Jaipur, Rajasthan, India.

Fischer NC57 Capacitive level sensor for conductive liquids (water, acid etc). Custom made for lengths starting at 400mm (40cm) all the way upto 2000mm (200cm) with various analogue outputs. The EU04 infra-red remote (sold separately) is required for commissioning and setting the min & max levels. The NC57 is ideally suited only for metal tanks, however can be used on non-metal tanks by adding an extra a earth roda

Principles of Operation
The metal rod needs to be mounted with
a fixed distance to the tank wall. It forms
a capacitor when charged with an A.C.
voltage. When the rod is immersed in a
liquid medium, the capacitance value is
a function of the immersed length. With
the probe fixed vertically downward, the
immersed length is proportional to the liquid level. The capacitance of the probe
is therefore a function of the level.
An electronic circuit module inside the
NC57 Level Sensor converts the capacitance value to a level measurement
and transmits as a linear standard electrical signal: 0-20 mA, 4-20 mA, 0-10 V
DC, 0-5 V DC, 1-5 V DC or 2-10 V DC.
